Leaf Chains consist of several applications and are regulated by ANSI. They are used for tension linkage, forklift masts and for low-speed pulling, and as balancers between counterweight and head in several machine devices. Leaf chains are occasionally even known as Balance Chains.
Features and Construction
Leaf chains are actually steel chains using a simple pin construction and link plate. The chain number refers to the lacing of the links and the pitch. The chains have certain features like high tensile strength for every section area, that enables the design of smaller mechanisms. There are B- and A+ type chains in this particular series and both the BL6 and AL6 Series comprise the same pitch as RS60. Finally, these chains cannot be driven with sprockets.
Selection and Handling
In roller chains, the link plates maintain a higher fatigue resistance due to the compressive stress of press fits, yet the leaf chain just contains two outer press fit plates. On the leaf chain, the maximum acceptable tension is low and the tensile strength is high. When handling leaf chains it is vital to check with the manufacturer's guidebook so as to ensure the safety factor is outlined and utilize safety guards at all times. It is a good idea to carry out extreme caution and utilize extra safety guards in functions wherein the consequences of chain failure are severe.
Using more plates in the lacing causes the higher tensile strength. For the reason that this does not enhance the maximum acceptable tension directly, the number of plates utilized may be limited. The chains need regular lubrication in view of the fact that the pins link directly on the plates, generating an extremely high bearing pressure. Utilizing a SAE 30 or 40 machine oil is normally suggested for nearly all applications. If the chain is cycled over 1000 times daily or if the chain speed is over 30m for each minute, it will wear very fast, even with continuous lubrication. Hence, in either of these situations utilizing RS Roller Chains would be more suitable.
AL type chains are only to be used under certain situations such as where there are no shock loads or if wear is not really a big problem. Make sure that the number of cycles does not go over one hundred each day. The BL-type will be better suited under other situations.
The stress load in parts will become higher if a chain using a lower safety factor is chosen. If the chain is also used among corrosive conditions, it could easily fatigue and break extremely quick. Doing frequent maintenance is really vital if operating under these kinds of conditions.
The type of end link of the chain, whether it is an outer link or inner link, determines the shape of the clevis. Clevis connectors or Clevis pins are constructed by manufacturers but normally, the user supplies the clevis. A wrongly constructed clevis could lessen the working life of the chain. The strands must be finished to length by the manufacturer. Check the ANSI standard or call the producer.
